Boilers for Carbon Black Industry
Manufacturing of carbon black mainly involves various unit operations like thermal cracking, heating, cooling and drying. Hot gases generated during cracking process are cooled in inline boilers, further Off gases that are generated is utilized as fuel in the steam boiler to generate high pressure steam and utilized for power generation.
Our design of Carbon Black Gas Boilers is suitable for turn-down ratio of 25% to 110% of MCR without support fuel, instead of 40% to 100% as in conventional design. Hence, better flexibility and fuel savings.
Tail Gas Boilers are suitable for steam temperature control range of 30% to 110% of MCR, instead of 50% to 100% as in conventional design. Hence, better flexibility.
Tail Gas boilers supplied by TSPL don't require support fuel till Off gas flow comes below 25% of MCR instead of 40% of MCR, or LHV fall below 450 Kcal/Nm³, as in conventional design. Hence, fuel saving.
In our design, the combustion is controlled by sensing the fuel gas temperature (more reliable) compared to Flame Scanner. This arrangement ensures smooth and steady operation and avoids tripping of the system.
TSPL has successfully executed many Tail Gas Boilers for off gases & Inline Boilers ( Tread Black | Carcass Black) for the Carbon Black Industry in India and Overseas.
128 TPH
Largest unit capacity
68 kg/cm²
Steam pressure
284 °C
Steam temperature
27
Installations in hydrogen units
Thermal Systems provides Tail Gas Boilers and Inline Boilers on Off Gases in Carbon Black Industry
- Turn-down ratio of 25% to 110%
- Steam control range of 30% to 110% of MCR
- No support fuel till off gas flow is below 25% of MCR
- Combustion control by fuel gas temperature sensing
- Inline boilers of vertical & horizontal construction suiting layout
Tail Gas Boiler
Manufacturing of carbon black mainly involves various unit operations like thermal cracking, heating, cooling and drying. Hot gases generated during cracking process are cooled in inline boilers, further Off gases that are generated is utilized as fuel in the steam boiler to generate high pressure steam and utilized for power generation.
High-pressure tail gas boilers firing off-gases, turndown 25–110% MCR without support fuel.
Inline Boiler / Reactor WHB
Manufacturing of carbon black mainly involves various unit operations like thermal cracking, heating, cooling and drying. Hot gases generated during cracking process are cooled in inline boilers, further Off gases that are generated is utilized as fuel in the steam boiler to generate high pressure steam and utilized for power generation.
Inline/reactor WHBs for tread and carcass black, vertical & horizontal construction.
